Membrane Filters

download support literature

Application Case Study

ACS-004 - Tank Vent for Citrus Juice

This application study focuses on the use of PTFE membrane filters in a citrus juice processing plant to prevent juice spoilage.

features & benefits:

download support literature

Application Case Study

ACS-008 Citric Acid Plant Condensate Water

This case study details how Graver GFP 1-30P7E filters improved condensate water filtration for a citric acid plant, overcoming rust and dirt issues.

features & benefits:

download support literature

Application Case Study

Backwashing of Microfiltration Cartridge Elements

This technical brief discusses the backwashing of microfiltration cartridge elements, a process used to clean filters by reversing flow to remove particles and extend filter life, particularly in applications like catalyst recovery and beer and wine bottling.

features & benefits:

download support literature

Citadel® Series

Citadel pleated membrane cartridges feature a PTFE membrane and PFA structural components to provide excellent chemical and temperature resistance for aggressive chemical applications such as etchers, strippers, cleaners and bulk chemicals.

features & benefits:

Manufactured, flushed, tested and packagedin an ISO Class 7 Cleanroom Environment
Filters are flushed with 18 MΩ-cm DI water toensure low extractables and low particle shedding
100% integrity tested to provide reliable performance
Resistivity rinse-up to 18 MΩ-cm and single digitppb TOC levels with minimal throughput
Pore size ratings from 0.05 to 10 micronto meet a broad range of applications
Wet-Pack option available to eliminate the requirementfor solvent pre-wetting in aqueous applications

download support literature

Cleaning/Sanitizing Filters

This technical brief provides the Cleaning and Sanitizing Procedure for Graver Filter Products.

features & benefits:

download support literature

End Configurations

Use this technical brief to explore Graver Technologies' wild variety of end configurations.

features & benefits:

download support literature

Glossary of Biotech Terms

Every industry has an abundance of terms that may be used to describe products and processes. Because of the critical nature of the pharmaceutical and biotechnology markets and the fact that it is highly regulated, it is critical to define and understand some of the more common terms.

features & benefits:

download support literature

Graver Cartridge Regeneration Procedures for Wine & Beer Applications

Explore Graver Technologies' Cartridge Regeneration Procedures for Wine & Beer Applications.

features & benefits:

download support literature

High Flow Sizing

This technical brief contains Housing Sizing Guidelines for Graver High Flow Filter Cartridges.

features & benefits:

download support literature

Integrity Testing: Pressure Hold

This technical brief identifies why integrity testing is crucial for membrane filters in bioburden control. Bubble point and diffusive flow are common, but Pressure Hold Test is recommended for multi-round housings.

features & benefits:

download support literature

Membrane Role in Microbial Retention

This technical brief explores the role of membranes in microbial retention.

features & benefits:

download support literature

Membrane Wetting

This technical brief explores Pre-Wetting Hydrophilic Membranes for Integrity Testing.

features & benefits:

download support literature

TB-022 Deep Well Injection

This document discusses the importance of filtration in liquid processing, focusing on deep well injection sites. It emphasizes the need for effective filtration to maintain the quality of injected fluids and avoid clogging.

features & benefits:

download support literature

TefTEC™ P Series

TefTEC™ P membrane cartridges offer complete bacterial retention and product sterility for biopharmaceutical final filtration.

features & benefits:

Singlelayer construction provides superior flow rates and minimizes filtration system size
100% Flushed with 18 megohm DI water and integrity tested
Filters are manufactured, flushed, tested and packaged in an ISO Class 7 Cleanroom Environment
Each filter element stamped with pore size, lot and serial number for identification and traceability
Complete bacterial removal in liquid at a challenge level of 107 /cm2 Brevundimonas diminuta
Retentive for aerosolized virus
Validation guide available

download support literature

TefTEC™ Series

TefTEC™ filters have PTFE membrane & polypropylene components, offering superior hydrophobicity and cost-effective alternative to all-fluorocarbon filters.

features & benefits:

High surface area, singlelayer construction provides superior flow rates and minimizes filtration system size
100% Flushed with 18 MΩcm DI water and integrity tested
Filters are manufactured, flushed, tested and packaged in an ISO Class 7 Cleanroom Environment
Each filter element stamped with pore size, lot and serial number for identification and traceability
Complete qualification guide available
Available prewet for use with aqueous based chemicals

download support literature

TefTEC™ V Series

TefTEC™ V cartridge filters are cost-effective with PTFE membrane & polypropylene support, ideal for compressed air and tank vent apps.

features & benefits:

Singlelayer construction provides superior flow rates and minimizes filtration system size
100% Flushed with 18 megohm DI water and integrity tested
Filters are manufactured, flushed, tested and packaged in an ISO Class 7 Cleanroom Environment
Each filter element stamped with pore size, lot and serial number for identification and traceability
Demonstrated bacterial removal in air with an aerosol challenge level of 107
Brevundimonas diminuta/10" cartridge
Complete qualification guide available

‍

download support literature

WaterTEC™ Series

The WaterTEC™ filter series is constructed of absolute rated, hydrophilic, asymmetric polyethersulfone membrane and polypropylene components.

features & benefits:

Low pressure drop reduces energy costs
High dirt holding capacity minimizes changeouts and down time
All thermal bonded construction with no adhesives
Available in all common configurations to allow use of existing filter housings
Cost effective absolute filtration

download support literature

ZTEC™ B Series

ZTEC™ B Bioburden Reduction grade membrane cartridges provide highly consistent performance for bioburden reduction and particle removal across a wide range of beverage, pharmaceutical and biological fluids.

features & benefits:

Manufactured in an ISO Class 7 Cleanroom Environment
100% flushed with ultrapure DI water and integrity tested
Repeatably steamable/sanitizable
High retentions up to 107/cm2 challenged for bacteria and yeast
Pore size, lot and serial number are stamped on each filter element for identification and traceability
Complete qualification guide available

download support literature

ZTEC™ E Series

The ZTEC™ E microelectronics grade cartridges by Graver are designed for ultrapure water filtration, and are hydrophilic and free of added surfactants to avoid contamination of water streams.

features & benefits:

Manufactured, flushed, tested and packaged, in an ISO Class 7 Cleanroom Environment
Filters are 100% flushed with 18 MΩcm DI water and integrity tested
Resistivity rinse up to 18 MΩcm and single digit ppb TOC levels with minimal throughput
Available in a variety of end cap/adapter configurations to fit all industry standard housings
Pore size, lot and serial number are stamped on each filter element for identification and traceability
Complete qualification guide available

download support literature

Performance Guide

ZTEC™ G Series

This pleated, disposable filter element is constructed of absolute rated, hydrophilic, asymmetric polyethersulfone membrane with extended filter area.

features & benefits:

7.0 ft2 (0.65 m2) of membrane surface area per 10" element — High throughput, longer online service reduces costly maintenance time
Absolute rated membrane from 0.1 to 0.65 μm
Manufactured in an ISO Class 7 cleanroom environment
100% flushed with 18 MΩ cm DI water and gross integrity tested
Fixed pore construction eliminates dirt unloading as differential pressure increases
Low extractables

download support literature

ZTEC™ P Series

ZTEC™ P Sterilizing Grade membrane cartridges are validated for complete bacterial retention to yield product sterility in biopharmaceutical final filtration applications.

features & benefits:

Manufactured in an ISO Class 7 Cleanroom Environment
100% flushed with ultrapure DI water
Meets ASTM Standards for Sterility
Repeatably Steamable/Sanitizable
100% Integrity tested prior to release
Pore size, lot and serial number are stamped on each filter element for identification and traceability
Complete validation guide available

‍

download support literature

ZTEC™ WB Series

ZTEC™ WB cartridge filters use PES membrane to remove spoilage organisms and inorganic particulate to protect beverages.

features & benefits:

Manufactured in an ISO Class 7 Cleanroom Environment
100% flushed with ultrapure DI water and integrity tested
Low adsorption of protein, color and flavor components
Steamable/sanitizable for cleaning and reuse
High log reduction values for spoilage organisms
PES membrane provides high capacity contaminant loading
Complete qualification guide available
Quick wet treatment available

download support literature
